Capacity50KVA ~3500KVA

Phase Three Phase

Primary Voltage4.16KV,12.47KV,13.2KV,13.8KV,24.94KV,34.5KV（Customizable）

Secondary Voltage480V,440V,420V,415V,400V（Customizable）

Frequency 60HZ

product details

Capacity 50KVA ~3500KVA

Phase Three Phase

Primary Voltage 4.16KV,12.47KV,13.2KV,13.8KV,24.94KV,34.5KV（Customizable）

Secondary Voltage 480V,440V,420V,415V,400V（Customizable）

Frequency 60HZ

Cooling way ONAN

Tape changer 5Position,2*±2.5%（Customizable）

Temperature Rise 60℃

Primary Insulation Well Bushing

Secondary Connection Standard Spade Connectors

Efficiency Meet DOE 2016 Standard

Insulation Mineral oil

Liquid level Gauge Available

Temperature Gauge Available

Fill Valve Available

Drain Valve w/ Sampler Available

Protection fuses Bavonet fusing

Load break Switch 2 or 4-Position load break switch

Front Dead Front Primary, Live Front Secondary

Winding material Copper

Ambient Temperature rating -5℃-40℃

Sound Level <60dB

Housing Coated steel, Tamper Resistant w/Padlockable lift-up Lid

MountingPad Mount
